The Mini LoRaWAN Network Server is a compact Embedded Server that retains key features similar to an Industrial PC but is designed for lower power consumption.

Hardware Specifications

CPU: AMD Embedded G-Series GX-412TC

  • (1 GHz, quad-core Jaguar, รองรับ 64-bit AES-NI, 32K data + 32K instruction cache per core, L2 cache ขนาด 2MB)

Memory

  • 2GB or 4GB DDR3-1333 DRAM

Connectivity

  • 2 or 3 Gigabit Ethernet channels

I/O Ports

  • Serial Communication: DB9 serial port
  • USB Ports: 2x external USB 3.0, 2x internal USB 2.0
  • Front Panel: Three LEDs, push button

Storage & Power

Storage Options

  • Boot from m-SATA SSD

  • SD card (internal SDHC controller)
  • External USB
  • 1x SATA + power connector

Power Supply

  • 12V DC, approximately 6W to 12W depending on CPU load

  • Power Jack: 2.5 mm, center positive

Expansion Options

  • 2x miniPCI express

  • LPC bus
  • GPIO header
  • I2C bus
  • COM2 (3.3V RXD / TXD)
